52V Triangle eBike Battery 30Ah Lithium Pack + Premium Charger
Elemex 52V Triangle eBike Battery is suitable for up to 3000W Motors
Genuine LG Cells
+1 Year Warranty
eBike Battery 30Ah Lithium Pack + Charger
Product Overview:
The Elemex 52V 30Ah Triangle eBike Battery features a waterproof design with high-quality sealing technology, protecting against rain, splashes, and dust for all-weather reliability. Engineered with genuine LG cells, this lithium pack ensures optimal performance, longevity, and consistent power for motors up to 3000W. It includes a premium charger, making it a dependable choice for high-performance eBikes.
Battery Features:
- Brand: Elemex
- Cell Type: 21700 4800mAh Lithium-ion
- Cell Brand: LG (Genuine) – LG M48A Cell
- Nominal Voltage: 52V
- Array Mode: 14s6p
- Max Constant Discharge Current: 60A
- Max Continuous Charge Current: 5A
- Peak Discharge Current: 180A (3-5 Seconds)
- Way of charge: CC/CV
- Rated Capacity: 28.8Ah
- Charge Cut off Voltage: 58.8V
- Discharge Cut off Voltage: 39.2V ~ 42V
- Energy: 1492 Wh
- Charge/Discharge Temperature: -15 ~ 55 C
- Protections: Overheat, Over Charge, Over Discharge, Over Current, Short Circuit, Balance
- BMS: 60A
- Charging time: Approx. 5 to 10 hours
- Charger Compatibility: Elemex-approved chargers
- Output Connector: XT60 Female
- Housing material: ABS Plastic
- Compatible Brand: Elemex Conversion Kits, Universal
- Cycle life: 1100 times
- Weight: 7.5kg~
- Dimensions: Approx. 400mm x 350mm x 240mm~ – (Thickness: 8mm~)
- Warranty: 1 Year
BMS Protection:
This 52V Triangle eBike Battery Pack is equipped with a Battery Management System (BMS) that provides protection against overcharge, over-discharge, over-current, short circuits, and ensures cell balance for optimal performance and safety.
BMS Protection for 52V 28.8Ah Triangle eBike Lithium Battery Pack
Charger Features:
with 2Ah Charger:
- Brand: Elemex
- Input: AC 100-240V∼ 50/60Hz
- Output: DC 58.8V 2Ah [117.6W]
- Compatible Battery: 52V Lithium Li-ion
- Certifications: SAA, GMA, CE, ETV
- Warranty: 1 Year
52V Battery Charger 2Ah- Brand: Elemex
- Input: AC 100-240V∼ 50/60Hz
- Output: DC 58.8V 3Ah (176 W)
- Compatible Battery: 52V Lithium Li-ion
- Certifications: SAA, GMA, CE, ETV
- Warranty: 1 Year
52V Battery Charger 3Ah
Built with precision and meeting stringent Australian Standards, Elemex Battery Chargers are engineered to endure and excel in performance.
Important Information:
Compatibility
When purchasing an Elemex battery, ensure the voltages are paired correctly. For example, a 52V motor must be paired with a 52V battery. Controllers damaged due to reprogramming or incompatible pairing are not covered under warranty.
Dimensions Check
Please verify the dimensions of this item before placing your order.
Assistance
If you are unsure which battery to pair with your bike, please contact us for more information.
Package Includes:
- 1x Elemex 52V 30Ah Triangle eBike Elemex Lithium Battery Pack (Genuine LG Cells)
- 1x Elemex 58.8V 2Ah/3Ah Premium Lithium Battery Charger [Choose from the Variation Bar]
- 1x Adapter Cable XT60 (Male)
- 1x Premium Tear resistant Velcro set (Straps)
- 1x User Manual
- 1x Warranty Certificate
⚠️ Warning
Users are solely responsible for reading and understanding the Elemex Battery User Manual before use or charging to ensure safe operation.
Lithium batteries must only be charged with Elemex-authorised, certified, and standard Li-ion chargers.
Using aftermarket or uncertified chargers may lead to performance issues, reduced battery life, or potential safety risks such as overheating or malfunction.
The use of uncertified chargers voids the warranty, and any resulting damage, faults, or failures will be the sole responsibility of the user.
