Premium 60V 25Ah Rectangle Lithium Battery Pack with 80A BMS

Rectangular Battery ebike 60V 25Ah Li-ion Pack with 80A BMS

Elemex Rectangle eBike Battery 60V 25Ah – Ideal for Up to 3000W Motors

Genuine Samsung Cells

+1 Year Warranty

*** PRE-ORDER ONLY! THIS PRODUCT IS CURRENTLY OUT OF STOCK. THE EXPECTED DELIVERY IS LATE-MAY-2025.***

60V 25Ah Rectangular eBike Battery

Product Overview:

The Elemex 60V Battery 25Ah Rectangle Li-ion Pack is designed to provide reliable power for eBikes, supporting motors up to 3000W. This high-performance battery pack is built with genuine Samsung cells, ensuring durability and efficiency.

Battery Specifications:

• Brand: Elemex
• Battery Type: 21700 5000mAh Lithium-ion Battery
• Cell Brand: Samsung (Genuine) – Samsung 50S Cell
• Array Mode: 16s5p
• Nominal Voltage: 60V
• Rated Capacity: 25Ah
• Energy: 1480W
• Max Constant Discharge Current: 80A
• Peak Current: 240A (3-5 Seconds)
• Max Constant Charge Current: 7A
• Cut-off Voltage: 40V
• Charge Voltage: 67.2V
• Charging Method: CC/CV
• Charge/Discharge Temperature: -20°C to 70°C
• BMS: 80A
• Protections: Overheat, Over Charge, Over Discharge, Over Current, Short Circuit, Balance
• Charging Time: Approx. 4 to 12 hours
• Charging Compatibility: Elemex-approved Chargers
• Output Connector: XT90 Female
• Battery Colour: Blue
• Charging Connector: 3 Pin XLR 18mm
• Cycle Life: 1100 cycles
• Battery Weight: Approx. 9 kg
• Battery Dimensions: Approx. 375mm x 130mm x 75mm
• Safety Certificates: CE, ROHS, MSDS, UN38.3
• Warranty: 1 Year

BMS Protection:

This 60V Rectangle eBike Battery Pack is equipped with a Battery Management System (BMS) that provides protection against overcharge, over-discharge, over-current, short circuits, and ensures cell balance for optimal performance and safety.

Important Information:

Compatibility and Installation:

• Ensure voltage pairing: A 60V motor must be paired with a 60V eBike battery.
• Controllers burnt out due to reprogramming or incompatible pairing are not covered by the warranty.
• For dual suspension bikes or limited frame space, consider using two smaller capacity batteries.

Precautions:

• Check dimensions before ordering.
• If uncertain about compatibility, contact us for assistance.

Package Includes:

• 1x Elemex 60V Battery 25Ah Rectangle Li-ion Pack (Genuine Samsung Cells)
• 1x Male XT90 to XT60 Female Adapter
• 1x User Manual
• 1 Year Warranty Certificate

Make sure your eBike has the power it needs with the Elemex 60V 25Ah Rectangle Li-ion Pack. Order now and enjoy a reliable, high-capacity battery backed by a 1-year warranty!

⚠️ Warning

Users are solely responsible for reading and understanding the Elemex Battery User Manual before use or charging to ensure safe operation.
Lithium batteries must only be charged with Elemex-authorised, certified, and standard Li-ion chargers.
Using aftermarket or uncertified chargers may lead to performance issues, reduced battery life, or potential safety risks such as overheating or malfunction.
The use of uncertified chargers voids the warranty, and any resulting damage, faults, or failures will be the sole responsibility of the user

Contact Us

If you have any questions about selecting the right battery for your eBike, scooter, or mobility device, please don’t hesitate to reach out to us for more information.
