Elemex Premium 5000W Brushless Direct Drive (Gearless) Rear hub Motor + Rim

Elemex Premium Rear 5000W Hub Motor + Rim Suitable for Electric Bike and Scooter

+1 Year Warranty on All Parts

*** PRE-ORDER ONLY! THIS PRODUCT IS CURRENTLY OUT OF STOCK. THE EXPECTED DELIVERY IS MID TO LATE-APRIL-2025.***

5000W Electric Bike Rear Motor Wheel Hub + Rim

Product Overview:

Elemex 5000W Brushless Direct Drive (Gearless) Electric Rear Motor Wheel Hub is a type of electric motor commonly used in electric bicycles (eBikes), scooters, and other light electric vehicles.

KEY FEATURES:

Power Output:

• Rated at 5000W, suitable for urban commuting, leisure riding, and terrains with Steep gradients.
• Complies with legal limits for eBikes in many regions.

Direct Drive (Gearless) Design:

• No internal gears, relying solely on the magnetic interaction between the rotor and stator.
• This design eliminates mechanical wear and tear from gears, enhancing durability.

Brushless Motor:

• Uses electronically controlled magnets instead of brushes, reducing maintenance.
• Offers higher efficiency, smooth acceleration, and less noise.

Quiet Operation:

• Gearless design significantly reduces noise compared to geared motors.
• Suitable for riders who prefer a stealthy and smooth ride.

Regenerative Braking:

• Many direct-drive hub motors support regenerative braking, converting some kinetic energy back into battery charge during deceleration.

Applications:

• High-Performance eBikes: Ideal for riders seeking higher speeds and powerful acceleration.
• Long-Distance Commuting: Suitable for daily use with enhanced speed and efficiency.
• Off-Road Biking: Handles trails, hills, and uneven terrains with ease.

Note: This kit is built for off-road adventures only. Be sure to check local laws to ensure it’s right for you. For a safe first ride, DIYers should get a final check from a licensed installer before hitting the road.

Attention: The buyer is solely responsible for ensuring the safe installation, use, and compliance with local laws and regulations for this product.

Product Specifications:

• Brand: Elemex
• Hub Motor Type: Brushless 50H Magnets Direct Drive (Gearless)
• Wiring Type: Integrated Waterproof Cable
• Wheel Size: 17″, 19″, 26″, 27.5″, 29″ (Optional)
• Rim: Aluminium Alloy double wall Durable 33mm internal rim width (Best suited for 2.35″ to 2.5″ wide tyres)
• Drop Out: 150mm
• Max Torque: 160Nm
• Rated Power: 5000W
• Rated Speed: 90km/h
• Max Speed: 100km/h
• Spokes: 36H-10G
• Weight: Approx. 9.5kg
• Wheel Axle: M14*10/218mm
• Load Capacity: 150 kg (including the total weight of the bike and rider)
• Hub Motor Safety Certification: CE, EN15194, RoHS
• Warranty: 1 Year on all parts

Package Includes:

• 1 x Elemex 5000W Brushless Hub Motor
• 1 x Quality 12G Alloy double wall Rim [Please select your rim size]

Safety Accessories:

For safety and durability during high-torque operation, it is highly recommended to install torque arms on both sides of the bike. These prevent axle spinning inside the dropouts, which could damage the motor wiring. Torque arms are sold separately.

Transform your ride and redefine your journey with our 5000W Motor Hub wheel. Experience smooth, effortless rides, greater range, and the freedom to explore without boundaries!
